SN

Title

Model,Specification,Value

1

General

Chassis Brand

Dongfeng

2

Vehicle Size(L*W*H)

9500*2280*3600

3

GVW(kg)

25000

4

Cab

Cab Capacity

3

5

Chassis

Drive Type

6X4（Left Hand Drive）

6

EngienType

C260 33

7

Engine cylinder

Inline six-cylinder electronic control system

7

Engine Power

260hp

8

Maximum output power

191kW

9

Emission Standard

Euro 3

10

Wheelbase(mm)

4350+1350

11

Tire size

12.00R20-18PR

12

Tyre number

10

13

Maximum speed

90km/h

14

Transmission

9JS119T-B

15

Gear shifting method

Manual

16

Forward gear

9gears

17

Number of reverse gears

1gears

18

Rated speed

2200rpm

19

Maximum torque

1090N.m

20

Paint

Commission

21

Front axle/ Rear axle

7T/10T

22

Fuel type

Diesel

23

Fuel capacity

350L

SN

Title

Model,Specification,Value

1

Capacity

14000L

2

Material of tank

High quality carbon steelQ235B(6mm)

3

Inner surface

Internal anti-corrosion coating

4

Tank rear end

Install heavy-duty doors with tight rubber seals.

5

Suction pump

Italian-imported PN155 vacuum pump for film selection.

6

Water pump

Yifeng 50-110 Sprinkler Pump

7

Water Pump head

110m

8

flow rate

50m3/h

9

Practical power

24KW

10

Tank Thick

6mm

11

End plate

5mm

12

Baffle plate

5mm

13

Number of baffles in the tank

1

14

Cleaning access hole

1each required

15

Safety valve

1 each required

16

Suction & delivery valve

1each required

17

Drain separator

1each required

18

Sludge level meter

With

19

Safety valve

1

20

Suction &delivery valve

1

21

Drain separator

1

22

               No.of    hoses

8

23

Hoses Length

4 meters each

24

Hoses Diameter(internal)

100 mm

25

Sludge level gauge

Standard

26

Water spray bar

Galvanized steel ， Equipped with a fast-acting discharge valve that can be controlled from the driver's cab

27

Drinking water container capacity

5L

28

Drinking water container materials

Galvanized steel

29

Toolbox

With

30

Hydraulic jack with a wheel wrench

With

31

Grease gun

With

32

User Manual,Parts manual, repair manual

1

33

Oil filter elements

5 unit with each

34

Fuel filters

5 unit with each

35

Electrical fuses and bulbs

2 unit each

36

Engine top overhaul gasket

1 set

37

Belts

1 each

38

Fluid, brake and air hoses

1 each

39

Air cleaner elements (if dry type)

5 each

40

Clutch disc

1 each

41

Nozzles

2 units each set

42

Injector assembly

1 unit each set

43

Brake linings

2 unit each set

44

Rubber wiper blade

1 unit each
