Model,Specification,Value

Chassis Brand

Dongfeng

Vehicle Size(L*W*H)

7660×2500×3200

GVW(kg)

16200

Cab Capacity

3

Drive Type

4X2(Left Hand Drive)

EngienType

D4.5NS6B240

Engine brake

Air brake

Power

240HP/176KW

Displacement

4.5L

Maximum torque

850N・m

Emission Standard

Euro 6

Wheelbase(mm)

3900

Tire size

9.00R20

Tyre number

6

Maximum speed

89

Gearbox

manual

Transmission

8-speed gearbox

Front axle/ Rear axle

3.9T/8T

Suspension

Leaf spring suspension

Brake

Front and rear dual-circuit drum brakes; exhaust brake

Configuration

With air conditioning, ABS,,Rearview mirror, seat belt, sun visor, fire extinguisher, floor mat, emergency warning triangle

Title

Model,Specification,Value

Tank volume

10 m³

Tank material

Carbon steel

Tank thickness

4MM

Tank shape

Oval-shaped tank,Three horizontal anti-surge baffles divide the water tank into four interconnected compartments.

Two inspection wells, each with an opening diameter of 50 centimeters.

Configuration

The top has a perforated steel plate walkway

3-inch galvanized pipe and rear ball valve

Two 30-meter-long hoses and connectors

Mudguards, overflow hose, loading ladder, hose box, rear bumper, spare tire rack, rear hook

Drive Pump

Model：80QZF-60/90N

Flow：60 m³/h

Lifting Head：90M

Import and export：80 mm

Equipped

Includes all necessary adapters, valves, valve caps, short pipes, elbows, and tees.

Durable truck vinyl stickers, 100 x 100 cm, 120 microns, 2 stickers per vehicle.
