Model,Specification,Value

Chassis Brand

Dongfeng

Vehicle Model

CL5181ZYS6AQC

Vehicle Size(L*W*H)

8530x2550x3500

Total mass(kg)

16000

Curb weight(kg)

10500

Rated mass(kg)

5900

Cab Capacity

3

Drive Type

LHD 4×2

Fuel Type

Diesel

Fuel tank

400L

Engine Type

Inline-six, turbocharged and intercooled

Engine Make &Model

ISD300 50

Power

221kw/300HP

Displacement

6.7L

Maximum Torque

1100N.m

Emission Standard

Euro 5

Wheelbase(mm)

4500

Tire size

10.00R20

Tyre number

6+1

Maximum speed

90km/h

Transmission

9JS119TB

Paint

Customization

Front axle/ Rear axle

6.5T/13T

Other Configurations

Air conditioning, ABS, multi-function steering wheel

Effective volume of box (m3)

14CBM

Case material

Q355 manganese steel

Box wall thickness

5MM

Bottom thickness of the casing

5MM

Operation mode

electronic/manual/remote control

Compression ratio

7:1

Hydraulic system pressure

18Mpa

Cyclic efficiency

Loading ≤15s compression ≤25s unloading ≤110s

Electro-hydraulic configuration

Gear pump, multi-way valve, balance valve, compression valve, shut-off valve, hydraulic

cylinders (all cylinders are heat-treated and have buffers), high-pressure oil pipes (3 layers of steel wire), universal steel pipes (2.2mm thick) 18#

thickened, hydraulic oil tank with 3-stage filter screen, all cylinder shaft pins are hardened to increase hardness and prevent bending and

breakage, CAN bus intelligent screen one-button

operating system with wireless remote control, system program can be customized on the

intelligent screen according to user needs,

automatic operation switching time and throttle control can be set, with automatic fault detection and

alarm functions.
